SensGrid

When to use

To compare a small number of methods (rows, via SensRow) across a small number of conditions or variants (columns). Best for 2–5 columns and 2–6 rows. Use this instead of a vanilla <table> when readers must scan across rows (method-to-method) more than down columns.

Example

import SensGrid from '../../components/widgets/SensGrid.astro';
import SensRow from '../../components/widgets/SensRow.astro';

<SensGrid columns={["clean", "noisy", "ablated"]}>
  <SensRow label="M1" cells={["0.91", "0.87", "0.62"]} />
  <SensRow label="M2" cells={["0.88", "0.84", "0.71"]} />
  <SensRow label="M3" cells={["0.93", "0.90", "0.74"]} />
</SensGrid>

Props

SensGrid

Prop	Type	Required	Notes
columns	string[]	yes	Column headers, left to right. The leftmost cell of the header row is empty (reserved for the row label column).

SensRow (companion)

The SensRow you put in the slot should take a label and an array of cell values matching columns.length.

When not to use

• For raw numeric data tables (use <table> or a CSV).
• For a single-row comparison (use PairList or prose).
• When columns are independent measurements with different scales — readers will misread the grid as comparable.
